| Color/Finish |
| Body |
Color |
Black |
Black |
Black |
| Size/Weight |
| Dimensions |
Width |
1,017 mm (40-1/16") |
1,017 mm (40-1/16") |
1004 mm |
| Height |
139 mm (5-1/2") |
139 mm (5-1/2") |
134 mm |
| Depth |
431 mm (17") |
431 mm (17") |
410 mm |
| Weight |
Weight |
11.6 kg (25 lb, 9 oz) |
11.6 kg (25 lb, 9 oz) |
8.1 kg |
| Packing Box |
Width |
1,174 mm (46-3/16") |
1,174 mm (46-3/16") |
1,110 mm (43-11/16") |
| Height |
246 mm (9-11/16") |
246 mm (9-11/16") |
231 mm (9-1/8") |
| Depth |
511 mm (20-1/8") |
511 mm (20-1/8") |
528 mm (20-13/16") |
| Control Interface |
| Keyboard |
Number of Keys |
61 |
61 |
61 |
| Tipo |
Organ (FSB), Initial Touch |
Organ (FSB), Initial Touch |
Organ, Initial Touch |
| Touch Response |
Normal, Soft1, Soft2, Hard1, Hard2 |
Normal, Soft1, Soft2, Hard1, Hard2 |
Normal, Soft 1, Soft 2, Hard 1, Hard 2 |
| Other Controllers |
Joystick |
Yes (Assignable) |
Yes (Assignable) |
- |
| Control Knobs |
2 (Assignable) |
2 (Assignable) |
2 (assignable) |
| Assignable Buttons |
8 (A–F, 1–2) |
8 (A–F, 1–2) |
- |
| Pitch Bend |
- |
- |
Yes |
| Modulation |
- |
- |
Yes |
| Display |
Tipo |
TFT Color Wide VGA LCD |
TFT Color Wide VGA LCD |
TFT Color WQVGA LCD |
| Size |
800 x 480 dots (7 inch) |
800 x 480 dots (7 inch) |
480 x 272 dots (4.3 inch) |
| Touch Screen |
Yes |
Yes |
- |
| Color |
Yes |
Yes |
Color |
| Language |
English, German, French, Spanish, Italian, Chinese |
English, German, French, Spanish, Italian, Chinese |
English, German, French, Spanish, Italian, Japanese |
| Panel |
Language |
English, Chinese |
English, Chinese |
English |
| Voices |
| Tone Generation |
Tone Generating Technology |
AWM Stereo Sampling, AEM technology |
AWM Stereo Sampling |
AWM Stereo Sampling |
| Polyphony |
Number of Polyphony (Max.) |
128 |
128 |
128 |
| Preset |
Number of Voices |
1,587 Voices + 63 Drum/SFX Kits + 480 XG Voices |
1,377 Voices + 56 Drum/SFX Kits + 480 XG Voices |
850 Voices + 43 Drum/SFX Kits + 480 XG Voices |
| Featured Voices |
12 S.Articulation2, 15 S.Articulation+, 340 S.Articulation, 55 OrganFlutes, 82 MegaVoice, 31 Sweet!, 87 Cool!, 149 Live! |
9 S.Articulation+, 252 S.Articulation, 55 OrganFlutes, 54 MegaVoice, 31 Sweet!, 87 Cool!, 131 Live! |
73 S.Articulation!, 27 MegaVoice, 27 Sweet!, 64 Cool!, 71 Live! |
| Expandability |
Expansion Voice |
Yes (approx. 2 GB) |
Yes (approx. 1 GB) |
Yes (approx. 100MB max.) |
| Editing |
Voice Set |
Voice Set |
Voice Set |
| Compatibility |
XG, GM, GM2 (for Song Playback) |
XG, GM, GM2 (for Song Playback) |
XG, GM, GM2 (for Song Playback) |
| Part |
Right1, Right2, Right3, Left |
Right1, Right2, Right3, Left |
Right 1, Right 2, Left |
| Effects |
| Types |
Reverb |
59 Preset + 30 User |
59 Preset + 30 User |
52 Preset + 30 User |
| Chorus |
107 Preset + 30 User |
106 Preset + 30 User |
106 Preset + 30 User |
| DSP |
358 Preset (with VCM) + 30 User |
322 Preset + 30 User |
295 Preset + 30 User |
| Insertion Effect |
Block 1-13: 358 Preset (with VCM) + 30 User |
Block 1-9: 322 Preset + 30 User |
- |
| Master Compressor |
5 Preset + 30 User |
5 Preset + 30 User |
5 Preset + 30 User |
| Master EQ |
5 Preset + 30 User |
5 Preset + 30 User |
5 Preset + 30 User |
| Part EQ |
28 Parts |
28 Parts |
27 Parts |
| Others |
Mic/Guitar Effects: Noise Gate, Compressor, 3 Band EQ, Vocal Effect: 23 |
Mic/Guitar effects: Noise Gate, Compressor, 3 Band EQ |
Mic effects: Noise Gate x 1, Compressor x 1, 3 Band EQ |
| Arpeggio |
Yes |
Yes |
Yes |
| Vocal Harmony |
Number of Presets |
Vocal Harmony: 54, Synth Vocoder: 20 |
- |
- |
| Number of User Settings |
60 *The number is the total of Vocal Harmony and Synth Vocoder |
- |
- |
| Accompaniment Styles |
| Preset |
Number of Preset Styles |
575 |
450 |
415 |
| Featured Styles |
520 Pro Styles, 49 Session Styles, 6 Free Play Styles |
410 Pro Styles, 37 Session Styles, 3 Free Play Styles |
372 Pro Styles, 32 Session Styles, 10 DJ Styles, 1 Free Play |
| Fingering |
Single Finger, Fingered, Fingered On Bass, Multi Finger, AI Fingered, Full Keyboard, AI Full Keyboard, Smart Chord |
Single Finger, Fingered, Fingered On Bass, Multi Finger, AI Fingered, Full Keyboard, AI Full Keyboard, Smart Chord |
Single Finger, Fingered, Fingered On Bass, Multi Finger, AI Fingered, Full Keyboard, AI Full Keyboard, Smart Chord |
| Style Control |
INTRO x 3, MAIN VARIATION x 4, FILL x 4, BREAK, ENDING x 3 |
INTRO x 3, MAIN VARIATION x 4, FILL x 4, BREAK, ENDING x 3 |
INTRO x 3, MAIN VARIATION x 4, FILL x 4, BREAK, ENDING x 3 |
| Compatibility |
Style File Format (SFF), Style File Format GE (SFF GE) |
Style File Format (SFF), Style File Format GE (SFF GE) |
Style File Format (SFF), Style File Format GE (SFF GE) |
| Expandability |
Expansion Style |
Yes (Internal Memory) |
Yes (Internal Memory) |
Yes (Internal Memory) |
| Expansion Audio Style |
Yes (Internal Memory) |
- |
- |
| Other Features |
Chord Looper |
Yes |
Yes |
- |
| Style Section Reset |
Yes |
Yes |
Yes |
| Style Section Change Timing |
Yes |
Yes |
- |
| Style Section Time Signature |
Yes |
Yes |
- |
| Style Dynamics Control |
Yes (with knobs / pedal) |
Yes (with knobs / pedal) |
- |
| One Touch Setting (OTS) |
4 for each Style |
4 for each Style |
4 for each Style |
| Unison & Accent |
- |
- |
Yes |
| Songs |
| Preset |
Number of Preset Songs |
1 Demo Song, 2 Preset Songs |
1 Demo Song, 2 Preset Songs |
3 Sample Songs |
| Recording |
Number of Songs |
Unlimited (depends on the drive capacity) |
Unlimited (depends on the drive capacity) |
- |
| Number of Tracks |
16 |
16 |
16 |
| Data Capacity |
Approx. 3 MB/Song |
Approx. 3 MB/Song |
Approx. 1 MB/Song |
| Recording Function |
Quick Recording, Multi Recording, Step Recording |
Quick Recording, Multi Recording, Step Recording |
Quick Recording, Multi Track Recording |
| Compatible Data Format |
Playback |
SMF (Format 0 & 1), XF |
SMF (Format 0 & 1), XF |
SMF (Format 0 & 1), XF |
| Recording |
SMF (Format 0) |
SMF (Format 0) |
SMF (Format 0) |
| Multi Pads |
| Preset |
Number of Multi Pad Banks |
500 banks x 4 Pads |
349 banks x 4 Pads |
188 Banks x 4 Pads |
| Audio |
Audio Link |
Yes |
Yes |
Yes |
| Functions |
| Voices |
Harmony/Echo |
Yes (with Arpeggio) |
Yes (with Arpeggio) |
Yes (with Arpeggio) |
| Panel Sustain |
Yes |
Yes |
Yes |
| Mono/Poly |
Yes |
Yes |
Yes |
| Voice Information |
Yes |
Yes |
Yes |
| Styles |
Style Creator |
Yes |
Yes |
Yes |
| OTS Information |
Yes |
Yes |
Yes |
| Songs |
Song Creator |
- |
- |
Yes |
| Score Display Function |
Yes |
Yes |
Yes |
| Lyrics Display Function |
Yes |
Yes |
Yes |
| Multi Pads |
Multi Pad Creator |
Yes |
Yes |
Yes |
| Registration |
Number of Buttons |
8 |
8 |
8 |
| Control |
Registration Sequence, Freeze |
Registration Sequence, Freeze |
Registration Sequence, Freeze |
| Playlist |
Number of Records |
2,500 (max.) Records per Playlist file |
2,500 (max.) Records per Playlist file |
500 (max.) Records per Playlist file |
| Search |
Registration Bank |
Registration Bank |
Registration Bank |
| Audio Recorder/Player |
Recording Time (max.) |
80 minutes/Song |
80 minutes/Song |
80 minutes/Song |
| Recording |
WAV (44.1 kHz, 16-bit, stereo), MP3 (44.1 kHz, 128/256/320 kbps, stereo) |
WAV (44.1 kHz, 16-bit, stereo), MP3 (44.1 kHz, 128/256/320 kbps, stereo) |
*only on USB .wav (WAV format: 44.1 kHz sample rate, 16 bit resolution, stereo) |
| Playback |
WAV (44.1 kHz, 16-bit, stereo), MP3 (44.1/48.0 kHz, 64–320 kbps and VBR mono/stereo) |
WAV (44.1 kHz, 16-bit, stereo), MP3 (44.1/48.0 kHz, 64–320 kbps and VBR mono/stereo) |
*only on USB .wav (WAV format: 44.1 kHz sample rate, 16 bit resolution, stereo) |
| Time Stretch |
Yes |
Yes |
Yes |
| Pitch Shift |
Yes |
Yes |
Yes |
| Vocal Cancel |
Yes |
Yes |
Yes |
| Demo/Help |
Demonstration |
Yes |
Yes |
Yes |
| Overall Controls |
Metronome |
Yes |
Yes |
Yes |
| Tempo Range |
5 - 500, Tap Tempo |
5 - 500, Tap Tempo |
5 - 500, Tap Tempo |
| Transpose |
-12 – 0 – +12 |
-12 – 0 – +12 |
-12 – 0 – +12 |
| Tuning |
414.8 – 440 – 466.8 Hz |
414.8 – 440 – 466.8 Hz |
414.8 – 440.0 – 466.8 Hz |
| Octave Button |
Yes |
Yes |
Yes |
| Scale Type |
9 types |
9 types |
9 types |
| Sub Scale Setting |
Yes |
Yes |
- |
| Miscellaneous |
Direct Access |
Yes |
Yes |
Yes |
| Text Display Function |
Yes |
Yes |
Yes |
| Wallpaper Customization |
Yes |
Yes |
- |
| Display Out |
Yes (by using a USB display adapter. You can check the list on "Downloads" > "Other Downloads"). |
- |
- |
| Bluetooth |
Yes (depends on destination) |
- |
- |
| Lesson/Guide |
Lesson/Guide |
Follow Lights, Any Key, Karao-Key, Your Tempo |
- |
Follow Lights, Any Key, Karao-Key, Your Tempo |
| Storage and Connectivity |
| Storage |
Internal Memory |
Yes (approx. 4 GB) |
Yes (approx. 1 GB) |
Yes (approx. 20 MB max.) |
| External Drives |
USB flash drive |
USB flash drive |
USB flash drive |
| Connectivity |
Headphones |
Standard stereo phone jack |
Standard stereo phone jack |
Yes |
| AUX IN |
Stereo mini jack |
Stereo mini jack |
Stereo mini jack |
| Extensive Connection |
Microphone |
Yes (Microphone/Guitar) |
Yes (Microphone/Guitar) |
Microphone x 1 |
| MIDI |
IN/OUT |
IN/OUT |
- |
| LINE OUT |
MAIN OUTPUT (L/L+R, R), SUB (AUX) OUTPUT (1, 2 (L/L+R, R)) |
MAIN OUTPUT (L/L+R, R) |
MAIN OUTPUT(L/L+R, R) |
| FOOT PEDAL |
1 (SUSTAIN), 2 (ARTICULATION 1), Function assignable |
1 (SUSTAIN), 2 (ARTICULATION 1), Function assignable |
1 (Sustain), 2 (Unison), Function Assignable |
| USB TO DEVICE |
Yes (× 2) |
Yes |
Yes |
| USB TO HOST |
Yes |
Yes |
Yes |
| Amplifiers and Speakers |
| Amplifiers |
(15 W+10 W) x2 |
15 W x2 |
15 W x 2 |
| Speakers |
13 cm x 2 + 2.5 cm (dome) x 2 |
13 cm x 2 + 5 cm x 2 |
12 cm x 2 |
| Power Supply |
| Power Supply |
PA-300C or an equivalent recommended by Yamaha |
PA-300C or an equivalent recommended by Yamaha |
PA-300C or an equivalent recommended by Yamaha |
| Power Consumption |
24 W |
21 W |
17 W |
| Auto Power Off Function |
Yes |
Yes |
Yes |
| Acessórios |
| Acessórios incluídos |
Owner's Manual, Music Rest, AC Adaptor (may not be included depending on your area. Check with your Yamaha dealer.) |
Owner's Manual, Music Rest, AC Adaptor (may not be included depending on your area. Check with your Yamaha dealer.) |
Owner's Manual, Online Member Product Registration, Music Rest, AC Adaptor (may not be include depending on your area. Check with your Yamaha dealer.) |
